Description
Marathon Symax super premium efficiency AC permanent magnet motor, high-performance inverter duty, 5hp, 3-phase, 230/460 VAC, 1800rpm, TEFC, NEMA 184TC frame, rolled steel, C-face/rigid base mount. Requires drive.
Brand: Marathon
Item: Motor
Series: Symax
Efficiency Group: Super premium efficiency
Efficiency: 93.9
Voltage Type: AC
Motor Type: Permanent magnet
Motor Application: High-performance inverter duty
Horsepower Rating: 5hp
Number of Phases: 3
Voltage Rating: 230/460 VAC
Synchronous Speed: 1800rpm
Nameplate RPM: 1800rpm
Overload Type: Maintained
Enclosure Type: TEFC
Shaft Type: Round with square key
Shaft Diameter: 1-1/8in
Shaft Material: 1045 hot rolled (C-204) steel
Motor Frame: NEMA 184TC
Frame Material: Rolled steel
Electrically Reversible: Yes
Insulation Class: Class F
IP Rating: IP43
Constant Torque Rating: 20:1
Variable Torque Rating: 20:1
Service Factor: 1.0
Integrated Brake: No
Junction Box Orientation: F1
Mounting: C-face/rigid base
Mounting Orientation: Horizontal or shaft down
Requires: Drive
Manufacturer Part Number: 184TPFRB10214
