Description
Gefran magnetostrictive linear position sensor, rodless slide, 100mm stroke, 4-20 and 20-4 mA output, 28.3 x 32 x 254mm, channel mount, 8-pin M12 quick-disconnect.
Brand: Gefran
Item: Linear position sensor
Transducer Type: Magnetostrictive
Action: Rodless slide
Stroke: 100mm
Output: 4-20 and 20-4 mA
Housing Material: Anodized aluminum
Housing Size: 28.3 x 32 x 254mm
Operating Voltage: 19.2-28.8 VDC
Sensor Resolution: Infinite
Linearity: +/- 0.02%
Mounting: Channel
IP Rating: IP67
Connection: 8-pin M12 quick-disconnect
Number of Wires: 8
Additional Information: Purchase cursor and mounting brackets separately
