Description
Sung-Il Machinery drive coupling hub, Oldham, aluminum alloy, clamp, size 57, 24mm bore. Requires SOH-57-DISC torque disc.
Brand: Sung-Il Machinery
Item: Drive coupling hub
Coupling Type: Oldham
Material: Aluminum alloy
Rated Torque: 34 N-m
Maximum Torque: 68 N-m
Maximum Angular Misalignment: 1.5 degrees
Maximum Parallel Misalignment: 3.5mm
Maximum RPM: 6000
Attachment Style: Clamp
Coupling Size: 57
Overall Length: 76.2mm
Bore Diameter: 24mm
Outside Diameter: 57mm
Clamp Screw Fastening Torque: 13 N-m
Clamp Screw Size: M6
Requires: SOH-57-DISC torque disc
