Description
Eaton Series C Type FD F-Frame molded case circuit breaker is rated at 100-Amps and 600-Volt AC/250-Volt DC at 50/60-Hz. The interrupt current rating of this circuit breaker is 35-Kilo-Amps at 480-Volt AC/18-Kilo-Amps at 600-Volt AC/10-Kilo-Amps at 250-Volt DC. It has non-interchangeable thermal-magnetic trip that opens the circuit to offer short circuit, ground fault and over current protection for sensitive equipment. The 1-Phase bolt-on mountable circuit breaker has load side terminal connection. It has a dimension of 2.75-Inch x 3.375-Inch x 6-Inch. This 2-Pole HACR rated circuit breaker is suitable for reverse feed use. It withstands temperature rating of 40 deg C.
