Description
Sung-Il Machinery drive coupling, servo-beam, 7075-T6 aluminum alloy, clamp, size 49, 19 x 20mm bore.
Brand: Sung-Il Machinery
Item: Drive coupling
Coupling Type: Servo-beam
Material: 7075-T6 aluminum alloy
Rated Torque: 15 N-m
Maximum Torque: 30 N-m
Maximum Angular Misalignment: 2.5 degrees
Maximum Parallel Misalignment: 0.25mm
Maximum RPM: 10000
Attachment Style: Clamp
Coupling Size: 49
Overall Length: 63.5mm
Bore Diameter: 19mm
Bore Diameter 2: 20mm
Outside Diameter: 49mm
Clamp Screw Fastening Torque: 13 N-m
Clamp Screw Size: M6
