Description
Mersen Amp-Trap® A4J Series Non-rejection current limiting fast acting fuse is ideal for use in capacitors, loadcenters, panelboards, switchboards, bus duct, feeder circuits, circuit breakers, lighting, heating and general loads. Fuse ensures high degree of current limiting for low-peak let-thru current. Class J fuse is rated at 200-Amps and 600-Volt AC/300-Volt DC. Interrupt rating of this fuse is 200-Kilo-Amps at 600-Volt AC and 100-Kilo-Amps at 300-Volt DC. Fuse with blade terminal connection, has cylindrical fiberglass polyester body for enhanced dimensional stability in harsh industrial environments. It has a unique dimension of 1-5/8-Inch Dia x 5-3/4-Inch. It supports clip mounting for easy installation. Fast-acting fuse is UL listed, CSA certified, RoHS compliant and meets IEC 269-2-1 standards.
Special Features:High current limitation for low peak let-thru current Unique dimensions prevent replacement by other fuse classes Fiberglass body provides dimensional stability in harsh industrial environments Easy-to-read imprint label for quick recognition and replacement
